Natural refrigerant R290
Thanks to the excellent thermodynamic performance of R290 and advanced heat pump technology, it helps to reduce carbon emissions and achieve carbon neutrality goals.Based on this, Haier has developed the R290 Super Aqua GT series.
Max Cop up to 5.50
The GT series has excellent performance. Higher compression ratio and lower oil compressors and the efficient internal thread regenerator is used in the appliance to increase the suction temperature and improve the energy efficiency of the unit. The maximum value of COP can reach 5.50.
Energy Efficiency Level A+++/A+++ (35°C/55°C)
The SCOP at 35°C and 55°C water temperature both reach the top class A+++.
Hot water ErP class A+
DHW efficiency level reach the top class A+.
High leaving water temperature
The max leaving water temperature can reach 80°C, leading in the industry. It is the best solution to replace the boiler heating.
Low sound level
With excellent design, the Haier Super Aqua GT series sound pressure level as low as 35dB(A) at 3 meters.
Super Convenience
Indoor wiring center ATW-A03N, connected with R290 Monobloc has minimized wiring work to make installation simple:
Compact design
All in one indoor unit covers an area of only 590*590mm, the smallest area in the industry, suitable for hidden installation of apartments.
Easy installation and easy maintenance
From the convenience of installation and maintenance the internal structure is optimized, the layout is more reasonable, and the components can be removed and assembled without interfering with each other.
Wide operating range
The GT series can operate normally at minus 25°C, and the heating capacity does not decay at minus 10°C, providing a guarantee for users to warm in cold weather.
Silver brazing technology
To deal with the R290 refrigerant which is combustible, optimize the system design by reducing welding joints and adopting silver brazing welding technology to ensure stronger welding and avoid leakage.
Refrigerant separator
Refrigerant separator can quickly discharge the refrigerant from the water system in case of leakage and prevent it from entering the water system and indoor space.
Sealed electric control box
Explosion-proof electric control design, more safety for R290 product, is used to avoid potential fire hazards and provide strong protection for user safety.
Smart control
With Haier Wi-Fi control, you can check the running state of heat and allows you to have flexibility and control of your heat pump. It deliver a simply life for you.
- Start and schedule programs, and receive notifications directly from anywhere
- Monitor real-time temperature and energy consumption data
- Over the air update save time and money for users and installers
Selection software
The system is built on the Cloud and authorized users to operate by browser. Users can visit the system by mobile terminals and computers. It can support all the ATW heat pumps models to select and design. The system can finally output the corresponding selected results and the overall project plan report.
| Product Data | Monobloc 8kW-1Ph |
Monobloc 12kW-1Ph |
Monobloc 16kW-1Ph |
Monobloc 16kW-3Ph |
||
|---|---|---|---|---|---|---|
| Model | AW082MUGHA | AW122MXGHA | AW162MXGHA | AW16NMXGHA | ||
| Heating (LWT 35°C / OAT 7°C) |
Capacity | kW | 8.00 | 12.00 | 16.00 | 16.00 |
| Power input | kW | 1.50 | 2.35 | 3.23 | 3.23 | |
| COP | W/W | 5.33 | 5.10 | 4.95 | 4.95 | |
| Heating (LWT 55°C / OAT 7°C) |
Capacity | kW | 8.00 | 11.50 | 15.50 | 15.50 |
| Power input | kW | 2.35 | 3.48 | 5.08 | 5.08 | |
| COP | W/W | 3.40 | 3.30 | 3.05 | 3.05 | |
| Space heating Average climate water outlet 35°C |
SCOP | - | 5.20 | 4.82 | 4.80 | 4.80 |
| ηs | % | 205 | 190 | 189 | 189 | |
| Energy class | - | A+++ | A+++ | A+++ | A+++ | |
| Space heating Average climate water outlet 55°C |
SCOP | - | 3.85 | 3.85 | 3.85 | 3.85 |
| ηs | % | 151 | 151 | 151 | 151 | |
| Energy class | - | A+++ | A+++ | A+++ | A+++ | |
| Cooling (LWT 18°C / OAT 35°C) |
Capacity | kW | 7.50 | 11.50 | 15.50 | 15.50 |
| Power input | kW | 1.58 | 2.56 | 3.88 | 3.88 | |
| EER | - | 4.75 | 4.50 | 4.00 | 4.00 | |
| Cooling (LWT 7°C / OAT 35°C) |
Capacity | kW | 6.80 | 10.00 | 14.00 | 14.00 |
| Power input | kW | 1.97 | 2.99 | 4.52 | 4.52 | |
| EER | - | 3.45 | 3.35 | 3.10 | 3.10 | |
| Outdoor operating temperature range |
Heating | °C | -25~35 | -25~35 | -25~35 | -25~35 |
| Cooling | °C | 10~48 | 10~48 | 10~48 | 10~48 | |
| DHW | °C | -25~43 | -25~43 | -25~43 | -25~43 | |
| Leaving water temperature range |
Heating | °C | 20~80 | 20~80 | 20~80 | 20~80 |
| Cooling | °C | 5~25 | 5~25 | 5~25 | 5~25 | |
| Storage temperature range(tank) |
DHW | °C | 25~75 | 25~75 | 25~75 | 25~75 |
| Water piping connection | Inlet/Outlet | R 1 / R 1 | R 1 / R 1 | R 1 / R 1 | R 1 / R 1 | |
| Expansion tank | L | 4.5 | 8 | 8 | 8 | |
| Compressor | Quantity | 1 | 1 | 1 | 1 | |
| Type | twin rotary | |||||
| Refrigerant | Type | R290 | R290 | R290 | R290 | |
| Charge/CO2 Eq. | kg/T | 0.9/2.7 | 1.05/3.15 | 1.25/3.75 | ||
| Net dimension | H*W*D mm | 790*1250*380 | 880*1380*460 | 880*1380*460 | 880*1380*460 | |
| Packing dimension | H*W*D mm | 1022*1395*550 | 1112*1526*630 | 1112*1526*630 | 1112*1526*630 | |
| Net/Gross weight | kg | 103/128 | 130/157 | 137/164 | 156/183 | |
| Sound pressure level*(1) | dB(A) | 48 | 52 | 55 | 55 | |
| Sound power level*(1) | dB | 59 | 63 | 66 | 66 | |
| Power supply | V/Ph/Hz | 220-240/1/50 | 220-240/1/50 | 220-240/1/50 | 380-415/3/50 | |
| Max running current | A | 18.6 | 30.6 | 34.8 | 11.6 | |
| Recommended circuit breaker | A | 20.0 | 32.0 | 40.0 | 16.0 | |
| Accessory | PCB Box* (2) | Model | ATW-A03N | |||
| Net dimension H*W*D / | 460*400*110 | |||||
| Packing dimension H*W*D / | 590*500*110 | |||||
| Net/Gross weight / kg | 8.09/11.12 | |||||
| Wired controller | / | HW-WA101DBT (built in ATW-A03N) | ||||
| Filter | / | Y-type(Standard) | ||||
