PIONEER MVH-330DAB Car Receiver, Bluetooth, DAB+, USB, 4 x 50 W
Shallow 1-DIN chassis with a detachable face: fits tight dashboards and deters theft.
The PIONEER MVH-330DAB is a mechless 1-DIN car receiver with built-in Bluetooth for hands-free calls and streaming, a USB input and a digital DAB+ tuner. It plays MP3, WMA, WAV and FLAC files from a USB stick, while the red display and key illumination blends into most factory interiors.
Bluetooth calling and music streaming
A built-in microphone lets you answer an incoming call with any button, while A2DP streaming puts track control on the front panel. One phone pairs at a time, using PIN 0000 on first connection.
DAB+ digital radio with external aerial
Band III reception (174.928–239.200 MHz) requires the CA-AN-DAB.001 aerial, sold separately, with power for it switched on in the DAB ANT menu. Six presets hold your favourite digital services, and classic FM/AM with RDS remains available.
FLAC playback straight from USB
The USB 2.0 port reads FAT12/16/32 media and supplies 0.5 A to keep a phone topped up. Beyond MP3 and WMA it handles WAV and FLAC, so your recordings keep their original quality.
MOSFET 50 W x 4 amplifier plus RCA pre-out
The on-board stage delivers 20 W x 4 continuous into 4 Ω, enough to drive replacement speakers without extra hardware. A rear RCA pre-out at 1.5 V feeds an external amp or powered subwoofer, and the 2-band graphic equaliser trims bass and treble across a ±12 dB range.
Specifications
General
Audio
Tuner
Connectivity
Display and controls
Power
Dimensions and weight
Warranty
| PLAYABLE FORMATS | MP3, WMA, FLAC |
| BLUETOOTH | Yes |
| MAX OUTPUT POWER | 4 X 50 W |
| REMOVEABLE FRONT PANEL | Yes |
| Brand | PIONEER |
| MODEL: | MVH-330DAB |
| PLAYABLE FORMATS: | MP3, WMA, FLAC |
| BLUETOOTH: | Yes |
| USB: | Yes |
| MAX OUTPUT POWER: | 4 X 50 W |
| TUNER TYPE: | FM/AM |
| RDS: | Yes |
| STATION MEMORY: | 18 |
| RCA OUTPUT: | Yes |
| REPEAT: | Yes |
| RANDOM: | Yes |
| DISPLAY TYPE: | LCD |
| DISPLAY COLOUR: | ЧЕРВЕН |
| LIGHTED BUTTONS: | Yes |
| REMOVEABLE FRONT PANEL: | Yes |
| WARRANTY: | 24 MONTHS |
| EAN | 4988028478239 |
